6000N/4000N Electric Linear Actuator from China manufacturer - Ningbo Orient Hisun Industrial Co.,Ltd.

Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HS-2005

Production Capacity: 1500 Pieces per week

Delivery Date: According to customers

Shape: Linear

Protect Feature: Enclosed

Function: Driving

Brand Name: Customized

Color: Black/Silvery White

Means of Transport: Ocean,Air

Packing: Canton packing

Structure: Others

Phase: Single-phase

Speed: Constant Speed

Usage: Electric Tool

Material: Aluminum

Certificate: CE, RoHS

Magnetic linear electric catuator
1.12V/24V/36V DC
2.Max. load 6000N/4000N
3.IP54
4.Max. stroke 450mm

Linear Actuator HS-2005

The linear actuators are widely used in electric sofas, massage chairs, dental chairs, electric medical beds, traction bed, television movements counters, furniture and other movements.

Technical data:

Model	HS-2005
Input voltage	12VDC/24V DC/36VDC
Max. Load	Thrust 6000N, pull 4000N
Duty cycle	10%, stop for 18 minutes after continuously working 2 minutes
IP grade	IP54
Limit switche	Built-in limit switch, non-adjustable
Operation temperature	+5°C~ +40°C
Min. Install dimension	195mm
Max. stroke	450mm
Tail connector	No rotation
Memory function	Optional
Colour	Black/Grey
